At Tolerance Tool, LLC, we understand that in today’s industry, the delivery of molds in shorter lead times is more important than ever. We also understand the need to deliver these molds at a competitive price without jeopardizing quality. Not only do we meet these expectations, we exceed them. Our team is comprised of highly skilled craftsmen, using robotic work cells to provide consistent quality and on-time delivery.

When each tool enters our 13,000 square foot manufacturing area, it has already been completely designed, and is continually being coordinated through all manufacturing departments. Tolerance Tool takes pride in our modern facility and team approach to deliver a quality product on time.

Let us reassure you of our high quality standards as you click on the links of our various departments below.

Mill Department

Our Mill Department is capable of maintaining the high quality standards we have established. Our skilled craftsmen who operate these machines recognize that their department is usually the first step toward the completion of a job, and use their expertise to ensure that the remaining operations can be performed successfully to produce a top quality product.

Mill Equipment List:

  • (3) Yasda CNC Jig Borer YBM640v ver. III (23.5 x 15.75 x 13.75 travel)
  • (2) Mikron HSM 300 High Speed Machining Center equipped with System 3R WorkMaster Robot
  • (1) Haas VF-8 (64″ x 40″ x 30″ travel)
  • (1) Haas VF-6-SS (64″ x 32″ x 30″ travel)
  • (1) Haas VF-6/50 Taper (64″ x 32″ x 30″ travel)
  • (2) Haas VM-3 Moldmaker (40″ x 26″ x 25″ travel)
  • (1) Haas VM-2 Moldmaker (30″ x 20″ x 20″ travel)
  • (1) Haas TL2 CNC Tool Room Lathe
  • (1) Cincinnati Bickford 9” x 4’ Radial Drill Press
  • (1) 2 Axis CNC Series 1 Bridgeport Mill
  • (1) 2 Axis CNC Series 2 Bridgeport Mill
  • (2) Manual Bridgeport Mill

Grinding Department

Precision grinding takes place in our vacuum-equipped grinding room.  Special attention to grinding and measuring equipment has ensured excellent quality and efficiency.

Grinding Equipment List:

  • (8) 6″ x 18″ Chevalier Surface Grinder with 2 Axis .0001 Readout
  • (1) 8″ x 18″ Mitsui Manual Grinder with Optidresser and 2 Axis .0001 Readout
  • (2) 12″ x 24″ Automatic Surface Grinder with 2 Axis .0001 Readout
  • (1) 16″ x 40″ Automatic Surface Grinder with 2 Axis .0001 Readout
  • (1) Moore #3 Jig Grinder with 2 Axis .0001 Readout
  • Hermann Schmidt Grinding Tooling

EDM Department

Our CNC Sinkers and Wire EDM machines are equipped with the latest technology.

Our team of skilled craftsmen combine many years of experience which ensure the highest quality precision tooling available.

EDM Equipment List:

  • (1) Mitsubishi EA12V Advance CNC Sinker EDM equipped with System 3R WorkPartner Robot, 150 stations
  • (1) Mitsubishi EA12V CNC Sinker EDM equipped with System 3R Workmaster Robot, 144 stations
  • (1) Mitsubishi EA12V CNC Sinker EDM equipped with System 3R 16 station tool changer
  • (2) Makino Duo43 4-axis Wire EDM with an ABB 6-axis robot automation loading both machines
  • (1) Makino U3 4-axis Wire EDM equipped with .004″, .006″, and .010″ wire
  • (1) Current EDM Drill MT30

Inspection Department

The inspection department programs our CNC Coordinate Measuring Machines directly from 3D Solids using Calypso Metrology software.

Inspection Equipment List:

  • (2) Carl Zeiss “Vista” CNC Coordinate Measuring Machine equipped with System 3R Pallet
  • (1) Carl Zeiss “Spectrum” CNC Coordinate Measuring Machine equipped with System 3R Pallet
  • (1) Numerex “EB” Coordinate Measuring Machine
  • Mitutoyo Inpection Equipment
  • Extensive range of Deltronic .0001 Increment Gage Pins
  • Calypso Metrology Software
